Customized commercial use 100kw 50kw hybrid solar system with 200kwh lithium battery solar system
The 50kW 100kWh Commercial Industrial Solar Battery Storage System is a powerful and versatile energy solution designed to meet the demanding needs of commercial and industrial applications.
Model: BSC-100KW-200.7KWh
Rated Output Power: 100kW
System Capacity: 200.7KWH
Battery Type: LiFePO4
Quality Guarantee: 10 Years
Inquiry Now  Datasheet
Product Appearance

Highlights:
·Bluesun provides the integrated system solution with one stop service

·Supports up to 50KW three-phaseoutput

·The entire system has beenfulytested and works perfecty

·Optimal configuration,high costperformance ratio

System Configuration

PV Power Equipment Model Unit Quantity Remark
BSC-100KW-200.7KWh

84.8kWp/100kW/200.7kWh

PV modules BSM565M10-72HPH pcs 150 15pcs/string,10string
Inverter BSE-100KH3 pcs 1 3P/400V
Batttery BSM48280H pcs 14 Power cable included
Control Box pcs 1 BAU included
Battery Rack pcs 1 2*8layers
Connector MC4 pair 4
PV cable PV1-F  1*4mm2 m 1000
Moniting WIFI module pcs 1 Optional
System Block Diagram

100KW/200.7KWH Energy Storage System

MODEL BSC-100KW-200.7KWh
System Parameter
AC rated power 100kW
Battery capacity 200.7kWh
AC voltage 3P/400V
Reted grid frequency 50/60Hz
Inveter Paramete
Model BSE-100KH3
Rated power 100KVA/100kW
Frequency 50/60 Hz
Nominal Voltage 230/400VAC
Max.Efficiengy 98.20%
Max.PV Voltiage (v) 1100VDC
PV Array MPPT Voltage Range 180-800VDC
Max.Solar Ihput Ourrent 32A
Max.Short Curent(A) 40A
Dimensions,D x W x H(mm) 510*820*1350
Weight (Kgs) 160
Battery Parameter
Model BSM48280H*14
Battery Type LiFePO4(LFP)
Nominal Voltage (v) 51.2
Nominal Capaclty (WH) 14336
Voltage Range V) 44.8-57.6
Max.Charge/Discharge Current(A) 280
Commuicaiton RS485/CAN
Weight (Kgs) 1744.5
Design Life 10 years
Cycle Life >6000@25℃
Environmemt
Maimum operation altitude 4000m
Working Temperature 0~50℃ Charge;-10℃~50℃ Dlischarge
Shelf Temperature -20℃-60℃
40ft bess container cases
